Date Code 20011026 Specifications 2-29
SEL-321/321-1 Instruction Manual
Table 2.10: Intermediate Elements
TAR Elements
26
ZT Z YT Y XT X W V
Table 2.11: Intermediate Element Summary
Element Comment
ZT
Z
YT
Y
XT
X
W
V
SEL
OGIC control equations Z Equation Output, Time Delayed
SEL
OGIC control equations Z Equation Output, Instantaneous
SEL
OGIC control equations Y Equation Output, Time Delayed
SEL
OGIC control equations Y Equation Output, Instantaneous
SEL
OGIC control equations X Equation Output, Time Delayed
SEL
OGIC control equations X Equation Output, Instantaneous
SEL
OGIC control equations W Equation Output, Instantaneous
SEL
OGIC control equations V Equation Output, Instantaneous
Table 2.12 lists internal elements which may be used singly to control output contacts for testing
purposes but are not available for SEL
OGIC control equations. Use SELOGIC control equations to
define MER, MTO, MTU, and MTCS. MER controls triggering of event reports. MTO, MTU,
and MTCS establish tripping conditions.
Table 2.12: Internal Elements
TAR Elements
27
RAG4 RAG3 RAG2 RAG1 MER MTO MTU MTCS
28
RCG4 RCG3 RCG2 RCG1 RBG4 RBG3 RBG2 RBG1
29
50AL4 50AL3 50AL2 50AL1 VPOLV N3PT L3PT PTRX
30
50CL4 50CL3 50CL2 50CL1 50BL4 50BL3 50BL2 50BL1
31
50G4 50G3 50G2 50G1 50CL 50BL 50AL *
32
OSB4 OSB3 OSB2 OSB1 50PP4 50PP3 50PP2 50PP1
33
TS TC TB TA * * ILOP 50P
34
SPT_EN * * * * 52AC 52AB 52AA
35
50AB4 50AB3 50AB2 50AB1 ATPC ATPB ATPA 50PPL
36
50CA4 50CA3 50CA2 50CA1 50BC4 50BC3 50BC2 50BC1
37
* 51NR 51QR 51PR * * * *
