Schweitzer Engineering Laboratories SEL-321 - Example Event Reports; Example Event Report 1

4-8 Event Reporting Date Code 20011026
SEL-321/321-1 Instruction Manual
Outputs Inputs
1 & 2 : Output 1 and Output 2 1 & 2 : Input 1 and Input 2
3 & 4 : Output 3 and Output 4 3 & 4 : Input 3 and Input 4
5 & 6 : Output 5 and Output 6 5 & 6 : Input 5 and Input 6
7 & 8 : Output 7 and Output 8 7 & 8 : Input 7 and Input 8
EXAMPLE EVENT REPORTS
Example Event Report 1
Example: BUS B, BREAKER 3 Date: 04/11/00 Time: 08:54:29.577
FID=SEL-321-1-R424-V656112-Z001001-D20000410
CURRENTS (pri) VOLTAGES (kV pri) RELAY ELEMENTS OUT IN
ZZZZZZO 555566L 1357 1357
ABCABCO 31110770 &&&& &&&&
IR IA IB IC VA VB VC BCAGGGS 2NQPPNQP 2468 2468
-4 -447 320 123 -129.3 89.1 40.7 ....... ........ .... ....
-2 -112 -328 438 -27.8 -98.5 125.8 ....... ........ .... ....
3 447 -320 -124 129.3 -89.1 -40.7 ....... ........ .... ....
-1 111 327 -439 27.8 98.4 -125.8 ....... ........ .... ....
One cycle of data
(Quarter-cycle
event report)
