Schweitzer Engineering Laboratories SEL-321 - Serial Port Settings; Serial Port Settings (See Appendix G for LMD and Appendix H for M IRRORED; Bits )

5-36 Applications Date Code 20011026
SEL-321/321-1 Instruction Manual
SETTINGS SHEET Page 10 OF 10
FOR THE SEL-321/321-1 RELAY Date
(5 A
NOMINAL RELAY)
Global Contact Input Settings
Input Contact 1 Assignment: IN1 = 52A1
Input Contact 2 Assignment: IN2 = PT
Input Contact 3 Assignment: IN3 = CLOSE
Input Contact 4 Assignment: IN4 = NA
Input Contact 5 Assignment: IN5 = NA
Input Contact 6 Assignment: IN6 = NA
Input Contact 7 Assignment: IN7 = NA
Input Contact 8 Assignment: IN8 = PTXFR
* Input Contact 9 Assignment: IN9 =
* Input Contact 10 Assignment: IN10 =
* Input Contact 11 Assignment: IN11 =
* Input Contact 12 Assignment: IN12 =
* Input Contact 13 Assignment: IN13 =
* Input Contact 14 Assignment: IN14 =
* Input Contact 15 Assignment: IN15 =
* Input Contact 16 Assignment: IN16 =
Received M
IRRORED BIT 1: RMB1 =
Received M
IRRORED BIT 2: RMB2 =
Received M
IRRORED BIT 3: RMB3 =
Received M
IRRORED BIT 4: RMB4 =
Received M
IRRORED BIT 5: RMB5 =
Received M
IRRORED BIT 6: RMB6 =
Received M
IRRORED BIT 7: RMB7 =
Received M
IRRORED BIT 8: RMB8 =
* INPUT9 - INPUT16 available only on two I/O board relays.
* OUT17 - OUT32 available only on two I/O board relays.
Miscellaneous Global Settings
Front panel timeout: (0 - 30 minutes) FP_TIMEOUT = 5
Group change delay: (0 - 900 seconds) TGR = 5
CR RAM Diagnostics Action: Restart Enable (Y/N) ERESTART = N
Serial Port Settings (See
Appendix G for LMD and Appendix H for MIRRORED BITS)
Protocol (SEL, LMD, MB, MB8) PROTOCOL = SEL
Baud Rate (300 - 38400) SPEED = 2400
Data Bits (6, 7, 8) DATA_BITS = 8
Parity (O, E, N) PARITY = N
Stop Bits (1, 2) STOP = 1
Timeout (0 - 30 min) TIMEOUT = 0
Send Auto Messages to Port (Y, N) AUTO = N
Enable Hardware Handshaking (Y, N, MBT) RTS_CTS = N
Fast Operate Enable (Y, N) FAST_OP = Y
