Schweitzer Engineering Laboratories SEL-321 - Example Event Report 2

4-10 Event Reporting Date Code 20011026
SEL-321/321-1 Instruction Manual
Example Event Report 2
BUS B, BREAKER 3 Date: 04/11/00 Time: 08:54:29.577
FID=SEL-321-1-R424-V656112P-Z001001-D20000410
CURRENTS (pri) VOLTAGES (kV pri) RELAY ELEMENTS OUT IN
ZZZZZZO 555566L 1357 1357
ABCABCO 31110770 &&&& &&&&
IR IA IB IC VA VB VC BCAGGGS 2NQPPNQP 2468 2468
-4 -447 320 123 -129.3 89.1 40.7 ....... ....L... .... 1...
-2 -112 -328 438 -27.8 -98.5 125.8 ....... ....L... .... 1...
3 447 -320 -124 129.3 -89.1 -40.7 ....... ....L... .... 1...
-1 111 327 -439 27.8 98.4 -125.8 ....... ....L... .... 1...
-6 -448 319 123 -129.3 89.1 40.7 ....... ....L... .... 1...
-3 -113 -328 438 -27.8 -98.4 125.8 ....... ....L... .... 1...
3 447 -320 -124 129.3 -89.1 -40.7 ....... ....L... .... 1...
0 112 327 -439 27.8 98.4 -125.8 ....... ....L... .... 1...
-5 -447 319 123 -129.3 89.1 40.7 ....... ....L... .... 1...
-3 -113 -328 438 -27.8 -98.4 125.8 ....... ....L... .... 1...
2 446 -320 -124 129.3 -89.1 -40.7 ....... ....L... .... 1...
0 112 327 -439 27.8 98.4 -125.8 ....... ....L... .... 1...
-6 -448 319 123 -129.3 89.1 40.6 ....... ....L... .... 1...
-2 -112 -328 438 -27.9 -98.4 125.8 ....... ....L... .... 1...
-582 -138 -320 -124 118.9 -93.4 -44.8 ....... ....L... .... 1...
1345 1457 327 -439 21.3 95.3 -129.0 ....... Qpp.M... .... 1...
810 368 319 123 -93.4 104.0 55.3 ....... Qpp.M... .... 1...
-3301 -3411 -328 438 -14.7 -92.1 132.2 ...1... Qpp.H... B4.. 1...
-459 -15 -320 -124 78.4 -110.4 -61.6 ...1... Qpp.H... B4.. 1...
3905 4017 327 -439 14.7 92.0 -132.2 ...1... Qpp.H... B4.. 1...
456 14 319 123 -78.4 110.4 61.6 ...1... Qpp.H... B4.. 1...
-3907 -4017 -328 438 -14.7 -92.0 132.2 ...1... Qpp.H... B4.. 1. ..
-460 -15 -321 -124 78.3 -110.5 -61.6 ...1... Qpp.H... B4.. 1...
3904 4016 327 -439 14.7 92.0 -132.3 ...1... Qpp.H... B4.. 1...
459 16 320 123 -78.3 110.4 61.6 ...1... Qpp.H... B4.. 1...
-3907 -4017 -328 438 -14.8 -92.0 132.3 ...1... Qpp.H... B4.. 1...
126 479 -206 -147 80.1 -108.5 -46.7 ...1... Qpp.H... B4.. 1...
2555 2610 228 -283 35.0 82.3 -129.8 ...1... Qpp.H... B4.. 1...
-359 -489 45 85 -98.0 111.4 15.1 ...1... Qpp.H... B4.. 1...
-604 -602 -65 63 -61.5 -69.0 130.1 ...1... Qpp.M... B4.. ....
0 1 -1 0 114.2 -116.3 1.5 ....... Qpp.M... B... ....
-2 -1 -1 0 67.8 65.3 -132.8 ....... .pp..... B... ....
-2 -2 0 0 -114.2 116.4 -1.5 ....... ........ B... ....
-1 0 0 -1 -67.8 -65.2 132.8 ....... ........ B... ....
1 2 -1 0 114.2 -116.4 1.5 ....... ........ B... ....
-1 -1 0 0 67.8 65.2 -132.8 ....... ........ B... ....
-4 -3 0 -1 -114.2 116.4 -1.6 ....... ........ B... ....
0 1 0 -1 -67.9 -65.2 132.8 ....... ........ B... ....
2 2 0 0 114.2 -116.4 1.6 ....... ........ B... ....
-3 -2 -1 0 67.8 65.2 -132.8 ....... ........ B... ....
-2 -2 0 0 -114.2 116.4 -1.6 ....... ........ B... ....
0 1 0 -1 -67.9 -65.2 132.8 ....... ........ B... ....
-1 1 -1 -1 114.2 -116.4 1.6 ....... ........ B... ....
-3 -2 -1 0 67.9 65.2 -132.8 ....... ........ B... ....
Event: AG Location: +14.92 Frequency: 60.0
Targets: INST ZONE1 EN A G V1 Mem: 132.1 / 77
Date and time-tag correspond to the
16th
q
uarte
r
-c
y
cle of this event
Firmware Identification Code
Input 1 (1) is energized
One cycle of data
50L element asserted
32QF element asserts
51N element asserts, event trigger
51Q element asserts, event trigger
50M element asserts
Zone 1, A-phase ground distance
asserted
50H element asserted
KEY bit asserted
Both OUT1 and OUT2 outputs
asserted b
y
3PT bit
A-phase ground fault at 14.92, system frequency is 60 Hz
Front panel targets, V1 memory mag [kV] and angle
r
e
f
e
r
e
n
ced
to
A-
p
h
ase
at
t
h
e
t
ri
gge
r in
sta
n
t
