EXAMPLE: BUS B, BREAKER 3 Date: 02/01/93 Time: 02:03:04.578
Active Group = 1
Group Variable = 1
=>>
Table 3.10: SET L Fail Message
Message Comment
Overall SELOGIC setting size too large. Try
combining equations.
Maximum of 160 SELOGIC terms exceeded.
SHOWSET L
SHOWSET L displays, but does not allow you to set, the programmable logic settings of the
currently selected group. Use the SHOWSET L command with a group number (1 - 6) to view
the logic settings of any group. You may enter parameters in any order following the SHOWSET
command. The following illustration shows a report from the one I/O board version (15 outputs)
of the relay.
=>>SHO L 1 <ENTER>
SHO L 1 <ENTER>SHO L 1 <ENTER>
SHO L 1 <ENTER>
SELogic group 1
V =NA
W =NA
X =NA
Y =NA
Z =NA
MTCS =M2P + Z2G
MTU =M1P + Z1G + M2PT + Z2GT + 51NT + 51QT + 50MF
MTO =M1P + M2P + Z1G + Z2G + 50H
MER =M2P + Z2G + 51NP + 51QP + 50H + LOP*52AA1
OUT1 =3PT
OUT2 =3PT
OUT3 =CC
OUT4 =KEY
OUT5 =NA
OUT6 =NA
OUT7 =NA
OUT8 =NA
OUT9 =NA
OUT10 =NA
OUT11 =NA
