3-18 Communications Date Code 20011026
SEL-321/321-1 Instruction Manual
Table 3.5: Variations on the SET Command
Command
Sets
Format
Application
Front
Panel
Note: Parameters following all SET commands may be entered in any order.
SET Group settings
(see Settings
Sheet in Section
5: Applications
for complete list)
SET
SET 1
SET 2 CTR
SET A
Set active group
Set Group 1
Set Group 2 starting at
entry CTR
Access all settings, even
if disabled
Yes
SET G Global settings SET G
SET G IN1
Set input assignments
Set front-panel timeout
Set group change delay
Set global settings
starting at entry IN1
Yes
SET P
Set
communications
port parameters
SET P
SET P 1
SET P 1 RTS_CTS
Set active port
Set Port 1
Set Port 1 starting at
RTS_CTS entry
Yes
SET L Program SELOGIC
control equations
SET L
SET L 1
SET L OUT2
SET L 1 OUT2
Program tripping, event
reporting, and
monitoring
conditions for active
logic group
Program above condi-
tions for Group 1
Program logic for active
group starting at
OUT2 entry
Program logic for
Group 1 starting at
OUT2 entry
No
(comm
ports
only)
