programmable mask and output assignments are as follows (one I/O board version - 15 outputs -
shown):
=>>SET L 1 <ENTER>
SET L 1 <ENTER>SET L 1 <ENTER>
SET L 1 <ENTER>
SELogic group 1
V =NA
?
W =NA
?
X =NA
?
Y =NA
?
Z =NA
?
MTCS =M2P + Z2G
?
MTU =M1P + Z1G + M2PT + Z2GT + 51NT + 51QT + 50MF
?
MTO =M1P + M2P + Z1G + Z2G + 50H
?
MER =M2P + Z2G + 51NP + 51QP + 50H + LOP*52AA1
?
OUT1 =3PT
?
OUT2 =3PT
?
OUT3 =CC
?
OUT4 =KEY
?
OUT5 =NA
?
OUT6 =NA
?
OUT7 =NA
?
OUT8 =NA
?
OUT9 =NA
?
OUT10 =NA
?
OUT11 =NA
?
OUT12 =NA
