2 Command Summary Date Code 20011026
SEL-321-1 Instruction Manual
TIME Shows or sets time. TIM 13/32/00 sets clock to 1:32:00 PM. IRIG-B synchronization
overrides this setting.
TRIGGER Triggers an event report.
Access Level B
CLOSE Asserts the CLOSE condition.
GROUP Specifies currently selected group. Use GROUP n to change selected group to n.
OPEN Asserts trip condition.
Access Level 2
CONTROL n Allows you to control Relay Word bits RB1 through RB16. (SEL-321-1 only)
COPY m n Copies settings and logic from setting Group m to Group n.
LOOP Enables M
IRRORED BITS loop back mode for testing communications
LOOP R Disables M
IRRORED BITS loop back mode.
PASSWORD Shows or sets passwords. Command pulses ALARM contacts closed momentarily
after password entry. PAS 1 OTTER sets Level 1 password to OTTER. PAS 2 TAIL
sets Level 2 password to TAIL.
PULSE n t Closes an output contact for testing and control purposes. (SEL-321-1 only)
RDMEM m Use to download contents of selected memory areas. m = RAM, EEPROM, or ALL.
SET n Use to enter group settings. If n argument omitted, edits active group.
SET G Use to enter new global settings.
SET L Use SET L n to edit Group n's logic settings. Selects active logic group to edit.
SET P Use SET P n to edit Port n's settings. Changes active port's settings.
TARGET Shows target values, and defines target group for display. TAR n displays target row
n. TAR R command resets front panel targets to TAR 1.
