Section17TECHNICALDATA
Subsection 06 (3D RFI MODEL)
ENGINE 3D RFI
New 0.020 - 0.033 mm (.0008 - .0013 in))
Connecting rod/piston pin
radial clearance
Wear limit 0.050 mm (.002 in)
Type
SAE 30 motor oil
Counterbalance shaft oil
Capacity 30 mL (1 U.S. oz)
ADDITIONAL INFORMATION:
ELECTRICAL 3D RFI
Wattage
270 W @ 6000 RPM
Magneto
generator output
Amperage 7 A @ 6000 RPM/13.5 volts
Ignition system type Digital Inductive
Make and type NGK BR8ES
Spark plug
Gap
0.4 - 0.5 mm (.016 - .020 in)
mm (in) 1.02 (.040)
Ignition timing
(BTDC)
Degrees 12°± 1.0 (fixed timing mode at any RPM)
Battery charging coil 0.1 - 1
Primary 0.3 -0.6
Ignition coil
Secondary Not applicable
Engine rev limiter setting 7200 ± 50 RPM
Battery 12 V, 19 A•h (Yuasa/Exide)
Main electrical system 20 A
MPEM 5A
Information center Not applicable
Fuel pump 10 A
Battery 15 A
Fuses
VTS system 10 A (installed but not in use)
Steering switch type
Normally opened
Steering switch resistance Open 470 ±5%
Steering switch resistance Close
82.5 ±5%
O.T.A.S.
Solenoid resistance 14.9 ±5%
ADDITIONAL INFORMATION:
FUEL SYSTEM 3D RFI
Fuel injection type Rotax Fuel Injection, semi-direct, single throttle body (56 mm)
Fuel pressure 56PSI-60PSI
Idle speed (in water) 1550 ± 100 RPM
Throttle Position Sensor (TPS)
1.6 k -2.4k (terminals 3-4)
710
- 1380 (terminals 4-11)
Crankshaft Position Sensor (CPS)
774 - 946
Air Temperature Sensor (ATS) 2.28 k -2.74k
Water Temperature Sensor (WTS)
2.28 k -2.74k
Air Pressure Sensor (APS)
3.4 -8.2 (terminals 2-9)
2.4
-8.2 (terminals 1-2)
84 smr2004-3D
