Section 17 TECHNICAL DATA
Subsection 06 (3D RFI MODEL)
FUEL SYSTEM 3D RFI
RAVE solenoid 30
Fuel injector 2.4 - 0.1
Type
Regular
unleaded gasoline
Fuel
Minimum octane no.
Inside North America: 87 (R + M) / 2
Outside North America: 91 RON
ADDITIONAL INFORMATION:
COOLING 3D RFI
Type
Open circuit — Direct flow from jet propulsion unit
Thermostat None
Monitoring beeper setting
86 - 94°C (187 - 201°F)
ADDITIONAL INFORMATION:
PROPULSION 3D RFI
Propulsion system BOMBARDIER Formula pump
Jet pump type Axial flow single stage
Impeller rotation (seen from rear) Counterclockwise
Transmission Direct drive
Coupling type Rubber coupling, split FR & RR
Oil type XP-S
TM
synthetic jet pump oil 75W90 GL5
Steering nozzle pivoting angle 20°
VTS nozzle pivoting angle
±9°
Minimum required water level 90 cm (35 in)
Drive shaft deflection (maximum) 0.5 mm (.020 in)
Impeller outside diameter 155.0 mm (6.102 in)
New 0.0 - 0.4 mm (.000 - .016 in)
Impeller/wear ring clearance
Wear limit 1.0 mm (.040 in)
Impeller shaft end play (new) 0
Impeller shaft side play 0.05 mm (.002 in)
Impeller pitch/material Progressive pitch 11° -20°/stainless steel
ADDITIONAL INFORMATION: Do not mix different brands or oil types.
DIMENSIONS 3D RFI
Number of passenger (driver incl.)
1
Overall length
272 cm (107 in)
Overall width 112 cm (44 in)
Overall height
Vert: 92 cm (36.25 in)
Moto: 112 cm (44.25 in)
Kart: 96 cm (37.75 in)
Dry weight
Moto/Vert: 268 kg (589 lb)
Kart: 274 kg (603 lb)
Load limit (passenger and luggage) 10 kg (22 lb) 114 kg (250 lb)
ADDITIONAL INFORMATION:
smr2004-3D 85
