Section17TECHNICALDATA
Subsection 06 (3D RFI MODEL)
CAPACITIES 3D RFI
Fuel tank (including reserve)
41L(10.8U.S.gal)
Fuel tank reserve (from low level signal) 6 L (1.6 U.S. gal)
Oil injection reservoir 4 L (1.05 U.S. gal)
Capacity 100 mL (3.4 U.S. oz)
Jet pump impeller shaft reservoir
Oil level height
Up to plug
ADDITIONAL INFORMATION:
MATERIALS 3D RFI
Hull Composite
Inlet grate Aluminum
Impeller housing/stator/venturi/nozzle Plastic/plastic/aluminum/aluminum
Air intake silencer Thermoplastic
Flame arrester Multi-layer wire screen
Steering padding
Thermoplastic
Fuel tank Polyethylene
Oil injection reservoir
Polyethylene
Seat Polyurethane foam
ADDITIONAL INFORMATION:
PERFORMANCE 3D RFI
Estimated pump power 42.6 kW (57 HP)
Maximum fuel consumption at wide open throttle 38 L/h (10 U.S. gal/h)
Fuel tank without reserve 55 minutes
Cruising time at full throttle
Fuel tank reserve (from low level signal) 102 minutes
ADDITIONAL INFORMATION:
86 smr2004-3D
