Secutron MR-2300T User Manual

71
11.3.3 Command Menu/MR-2300 Config -->I3 Zone
11.3.4 Command Menu/MR-2300 Config -->Opt Zone
This menu is used to program the process type of the indicating circuits. The maximum
number of indicating circuits is 4. Only those supported by the particular model are shown in
the CFG-300 Configuration Tool.
[ ] Zone-1->Default
.
.
.
[ ] Zone-12->Default
Use this menu if i
3
devices
are present on a zone. See
section 10.2 on page 57.
Note: Refer to section 11.2.1 on page 64 for detailed instructions on making menu
selections.
Command Menu/MR-2300 Config/Opt.
Zone
1.Process Type (Indicating Circuits)
|
|
|
4.
[X] SIL-ABLE->Default
[ ] NON SIL-ABLE
[ ] SIL-ABLE STR
[ ] NON-SIL STR
Use this menu to program
the process type of each
indicating circuit. See
section 9.8 on page 53.
[ ] Zone-1
[ ] Zone-2
--
--
I3 Detection Zones
[ ] Zone-12
i
1 NAC-1
2 NAC-2
3 NAC-3
4 NAC-4
Indicating Zone
NAC-1 Type
[X] SIL-ABLE
NAC-4 Type
[X] SIL-ABLE
