Secutron MR-2300T User Manual

72
11.3.5 Command Menu/MR-2300 Config-->Correlation
11.3.6 Command Menu/MR-2300 Config -->Inp Zone Label
Use the buttons described below for entering messages. These buttons are alternate functions
of bypass switches and are physically located in the same position as described following.
Note: Refer to section 11.2.1 on page 64 for detailed instructions on making menu
selections.
Command Menu/MR-2300 Config/
Correlation
1.Correlation
|
|
|
12.
[X] NAC-1 ->Default
[X] NAC-2 ->Default
[X] NAC-3 ->Default
[X] NAC-4 ->Default
Use this menu to correlate
initiating circuits to
indicating circuits. By
default all the initiating
circuits are correlated to all
the indicating circuits.
Note: Refer to section 11.2.1 on page 64 for detailed instructions on making menu
selections.
i
Zone-1 Corr.
[X] NAC-1
Zone-12 Corr.
[X] NAC-1
i
1 Zone-1
2 Zone-2
--
--
Initiating Zone
12 Zone12
