5.3.5 HANDSWITCH SUPPORT
1. T urn the Unit Off and Disconnect it from mains.
2. Place the Unit on a table.
It is not necessary to remove the Handle to access inside the Unit.
3. Remove the Upper Cover screws and carefully lift the Upper Cover . It is
not necessary to unplug any cable.
4. Unscrew the Handswitch Support and replace it.
Handswitch Support
Upper Cover
Note .
