5-1-3 Quick Commissioning
Start
Connection as per
wiring diagram
Power ON
Set Motor Parameters as per
nameplate data in P3 group
Select Frequency source in P0-01
Select Control mode in P0-02
Set Acc and Dec times in
P0-04 and P0-05
Select start and stop modes in
P2-00 and P2-05
Check protection levels in
P9 group
Start and observe
Optimize setings
