55
User Manual
The above parameters deal with the external communication feature of the drive. The parameter P11-00
defines the slave ID that will be assigned to the VFD. Note that the drive always acts as a slave in the
communication system. The parameter P11-01 defines the baud rate at which the communication
system will operate. P11-02 defines the MODBUS data format that will be used. Note that these
parameters need to be the same across all members of the communication system. The parameters
P11-04, P11-05, and P11-06 deal with customizable timeout settings for the
user. In systems where input is expected from the master device in every set period, this feature can be
used to generate a time-out action wherein one of the options from P11-06 will be performed. This action
will be triggered if no data is received from the master device in the time specified in P11-05. This feature
should be used only in cases where there is a continuous stream of data being transferred between the
drive and the master device. Otherwise, it could trigger an unnecessary fault.
PC – Enhanced parameters
PC-00
Acc. time 1
0.1 – 999.9 s
Default : 20.0 s
PC-01
PC-02
PC-03
PC-04
PC-05
Dec. time 1
Acc. time 2
Dec. time 2
Acc. time 3
Dec. time 3
0.1 – 999.9 s
0.1 – 999.9 s
0.1 – 999.9 s
0.1 – 999.9 s
0.1 – 999.9 s
Default : 20.0 s
Default : 20.0 s
Default : 20.0 s
Default : 20.0 s
Default : 20.0 s
The acceleration-deceleration times 1 through 3 are defined similarly as Acceleration- Deceleration
time 0 as defined in the P0 parameter family.
PC-06
Jog Acc. Time
0.1 – 999.9 s
Default : 5.0 s
PC-07
Jog Dec. Time
0.1 – 999.9 s
Default : 5.0 s
These 2 parameters define the acc/dec times for the jogging operation. Note that these times are
also defined as the transition time between the Max Frequency as defined in (P0-08) to 0Hz.
PC-08
Hopping Frequency
1 Lower Limit
Lower Limit Frequency (P0-10)
to Hopping Frequency 1 Upper
Limit (PC-09)
Default:
0.0 Hz
PC-09
Hopping Frequency
1 Upper Limit
Hopping Frequency 1 Lower
Limit (PC-08) to Upper Limit
Frequency (P0-09)
Default:
0.0 Hz
PC-10
Hopping Frequency
2 Lower Limit
Lower Limit Frequency (P0-10)
to Hopping Frequency 2 Upper
Limit (PC-11)
Default:
0.0 Hz
PC-11
Hopping Frequency
2 Upper Limit
Hopping Frequency 2 Lower
Limit (PC-10) to Upper Limit
Frequency (P0-09)
Default:
0.0 Hz
