P5-18
Terminal
Control Mode
0: Two-Wire Control Mode 1
1: Two-Wire Control Mode 2
2: Three-Wire Control Mode 1
3: Three-Wire Control Mode 2
0
Yes
40518
P5-19
Terminal
Filtering Time
2 ms- 100 ms
10 ms
No
40519
P5-20
Terminal
Frequency
updation Step
Size
0.0- Upper Limit of Frequency
(P0-09)
0.1 Hz
No
40520
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P6-01
Relay Output
Options
0: Disable; 1: Running;
2: Direction
3: Fault Output; 4: Pre-
Alarm;
5: Standby; 6: Frequency
arrived
7: Frequency detected
8: Upper Limit Frequency
9: Lower Limit Frequency
10: Setting Count Value
Received
11: Specified Count Value
Received
12: AI1 signal Loss
13: AI2 signal Loss
3
Yes
40601
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P6- OUTPUT FUNCTION PARAMETERS
P7- PI CONTROL PARAMETERS
P7-00
PI reference source
PI Refrence value
Feedback source
PI output
characteristics options
Proportional gain
0
0.00 %
0
0
1.0
No
40700
P7-01
No
40701
P7-02
No
40702
P7-03
No
40703
P7-04
No
40704
0: Keyboard
1: Analog channel
AI1 Current
2: Analog channel
AI2 Voltage
3: Analog channel
AI2 Potentiometer
0.00 % to 100.00 %
0: Currunt
1: Voltage
0: Positive;1: Negative
0.0 to 10.0
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
