Selec VFD Series

22
User Manual
Deviation limit
Sampling Time
Feedback
disconnection value
Feedback disconnection
detection time
2.0
0.2 s
0.1 %
10.0 s
P7-06
No
40706
P7-07
No
40707
P7-08
No
40708
P7-09
No
40709
0.0 to 20.0
0.1 to 100.0 s
0.1 % to 50.0 %
0.1 s to 100.0 s
Integral time
1.0 s P7-05
No
407050.0 to 100.0 s
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P8- SIMPLE PLC AND MULTISPEED OPTIONS
P8-00
Program run
mode
0: Disabled; 1: Program stops
after running for one cycle
2: Program runs for one cycle &
then continues at last operating
frequency
3: Circulatory running of the
program
0
Yes
40800
P8-01
First phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
11.0 Hz
No
40801
P8-02
Second phase
speed
Lower Limiting Frequency to
Upper Limiting Frequency
12.0 Hz
No
40802
P8-03
Third phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
13.0 Hz
No
40803
P8-04
Fourth phase
speed
Lower Limiting Frequency to
Upper Limiting Frequency
14.0 Hz
No
40804
P8-05
Fifth phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
15.0 Hz
No
40805
P8-06
Sixth phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
16.0 Hz
No
40806
P8-07
Seventh phase
speed
Lower Limiting Frequency to
Upper Limiting Frequency
17.0 Hz
No
40807
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P8-08
Runtime of
principal frequency
0.0-999.9 0.0
No
40808
P8-09
First phase time
0.0
No
40809
P8-10
Second phase
time
0.0
No
40810
P8-11
Third phase time
0.0
No
40811
P8-12
Fourth phase time
0.0
No
40812
P8-13
Fifth phase time
0.0
No
40813
0.0-999.9
0.0-999.9
0.0-999.9
0.0-999.9
0.0-999.9
