Selec VFD Series

P8-18
Acc-Dec Time for
each phase
0-65535 BIT0-15 indicated
acc/dec times for 0-7
Default: 0.0
Weighted value
Bit No.
Phase No.
Time selection
(example)
7
2
8
2
9
2
10
2
11
2
12
2
13
2
14
2
15
2
6
2
5
2
4
2
3
2
2
2
1
2
0
2
0
1
0 0 0 0 0 0 0
1 1 1 1
0 0 0
7 6
5
4
3
2 1
0
15
14
13
12 11
10 9 8 7 6
5
4
3
2 1
0
The P8-18 parameter determines the acceleration or deceleration times that will be followed for the
individual phases in the simple PLC program. In the 16-bit word, every 2-bit data corresponds to the
acc/dec time selection for the respective phase. The 2-bit data corresponds to 4 distinct Acc/Dec
times as shown in the table below.
MSB LSB
Acc/Dec time selection
Parameter Code
0 0 0 P0-04 and P0-05
0
1 1
P12-00 and P12-01
1
0
2
P12-02 and P12-03
1 1
3 P12-04 and P12-05
51
User Manual
In the example given above, phases 4 through 7 will follow acc/dec times 0;phases 0 and 1 will follow
acc/dec times 1; phase 2 will follow time combination 2; phase 3 will follow time 3. Converting the
time selection word from binary to decimal, we get (0000000011100101)2 = (229)10, which is the
value that needs to be stored in the parameter P8-18.
P9- Protection Parameters
P9-00
Overload protection
enable
0: Disable
1: Enable
Default: 1
P9-01
P9-02
P9-03
P9-04
P9-05
Critical value of
Overload protection
Overload detection
time
Overload pre-alarm
enabled
Overload pre-alarm
detection level
Overload pre-alarm
detection time
50 – 120 %
0.1 to 999.9 s
0: Disabled
1: Enabled
50 – P9:01
0.1 to 999.9 s
120 %
0.1 s
0
110 %
0.1 s
