Selec VFD Series

66
User Manual
Address Parameter
30000
Set Frequency
30001
Output Frequency
30002
Carrier Frequency
30003
Output current
30004
Output voltage
30005
Bus voltage
30007
%Full load current
30008
IGBT temperature
30009
%Output power
30010
Count value
30018
Fault code
9.5 Read-write rules of parameter address for function code
9.5.1 Monitoring Parameters
30006
Motor's RPM
Value stored Action
1
FWD Run
2
REV Run
5
FWD Jog
6
REV Jog
8
Coast to stop
9
Normal stop
10
E-Stop
15
Fault Reset
Value stored Action
9.5.3 Drive status
The address 30016 stores the current status of the drive.
Value
Stored Action
1
FWD Run
2
REV Run
3
Standby
4 Fault Condition
9.5.2 Commanding the drive over communication
The control register address is 42200. The register values and actions are mentioned in the table
below. Kindly note that the control mode for running (P0-02) should be set to “3: Control over
Communication” for these settings to work.
