P8 – Simple PLC and Multispeed parameters
P8-00
Program run
mode
0: Disabled
1: Program stops after running for one cycle
2: Program runs for one cycle and
then continues at last operating frequency
3: Circulatory running of the program
Default: 0
1: The program runs once and then the operation stops.
3: The program runs in a cyclic sequence continuously till deliberately stopped.
This parameter selects how the Simple PLC program will run0: Simple PLC operation is disabled.
2: The program runs once and then continues operating at the last
frequency in the sequence.
P8-01
First phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
Default:
11.0 Hz
P8-02
P8-03
Second phase
speed
Third phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
Lower Limiting Frequency to
Upper Limiting Frequency
Default:
12.0 Hz
Default:
13.0 Hz
P8-04
Fourth phase speed
Lower Limiting Frequency to
Upper Limiting Frequency
Default:
14.0 Hz
P8-05
P8-06
P8-07
Fifth phase speed
Sixth phase speed
Seventh phase
speed
Lower Limiting Frequency to
Upper Limiting Frequency
Lower Limiting Frequency to
Upper Limiting Frequency
Lower Limiting Frequency to
Upper Limiting Frequency
Default:
15.0 Hz
Default:
16.0 Hz
Default:
17.0 Hz
The parameters above determine the 7 phase speeds in the simple PLC program. The principal
frequency is set in parameter P0-03.
P8-08
The runtime of
principal frequency
0.0-999.9
Default: 0.0
P8-09
First phase time
0.0-999.9
Default : 0.0
P8-10
P8-11
P8-12
P8-13
P8-14
P8-15
Second phase time
Third phase time
Fourth phase time
Fifth phase time
Sixth phase time
Seventh phase time
0.0-999.9
0.0-999.9
0.0-999.9
0.0-999.9
0.0-999.9
0.0-999.9
Default : 0.0
Default : 0.0
Default : 0.0
Default : 0.0
Default : 0.0
Default : 0.0
These parameters determine the time for which the frequencies set in P8-01 to P8-07 will be running.
The operation is as shown in the timing diagram below.
