Selec VFD Series

P2- START AND STOP PARAMETERS
P2-00
Start mode
0: Direct Start
1: DC Braking Start
0
Yes
40200
P2-01
Starting frequency
0.0 – 10.0 Hz 0.5 Hz
Yes
40201
P2-02
Retention time
for starting
0.0 – 50.0 s 0 s
Yes
40202
P2-03
Braking current
before starting
0 – 150 % 50 %
Yes
40203
P2-04
Braking time
before starting
0.0 – 50.0 s 0 s
Yes
40204
P2-05
Stop mode
0: Coast to Stop
1: Ramp to Stop
2: DC Braking Stop
1
Yes
40205
P2-06
Start frequency
of DC braking
0 – 10.0 Hz 2.0 Hz
Yes
40206
P2-07
Braking current
for stopping
0 - 150 % 50 %
Yes
40207
P2-08
Braking time
for stopping
0.0 – 50.0 s 0.0 s
Yes
40208
P2-09
Demagnetizing
time
0.0 – 30.0 s 0.1 s
Yes
40209
P2-10
Dead time bet-
ween FWD/REV
0.0 – 50.0 s 0.2 s
Yes
40210
P2-11
Lower frequency
limit crossing
action
0: Running with low Limit
Frequency
1: Stopping
2: Standby
3: Hibernation
0
Yes
40211
P2-12
Hibernation
Restore Delay Time
0 – 50.0 s 0.0 s
Yes
40212
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
18
User Manual
P3 – MOTOR PARAMETERS
P3-00
Rated frequency F3 (P4-07) – 400.0 Hz
50.0 Hz
Yes
40300
P3-01
Rated Voltage
200-250 V
Depends
on Model
Yes
40301
P3-02
Rated Current
0.1- 5 A
Yes
40302
P3-03
Rated Power
Depends on Model
Yes
●
40303
Depends
on Model
Depends
on Model
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P3-04
No Load
0.1- Rated current
(P3-02)
No
●
40306
Depends
on Model
