P3- Motor Parameters
P3-00
Rated frequency F3 (P4-07) – 400.0 Hz
Default : 50.0 Hz
P3-01
Rated Voltage
Depends on Model
Default: Depends
on Model
P3-02
Rated Current
Default: Depends
on Model
P3-03
Rated Power
Default: Depends
on Model
P3-04
Default: Depends
on Model
No Load Current
0.1- Rated Current (P3-01)
36
User Manual
safety of the system as a whole.
The motor parameters are used for all protection and control calculations. These must reflect the
actual motor nameplate data for proper operation of the entire system. Incorrectness in this data can
hamper the efficiency and
P4- Scalar Control Parameters
P4-00
V/f curve setting
0: General V/f
1: 1.5 Power V/f
2: 1.7 Power V/f
3: 2 Power V/f
4: Multipoint V/f
Default: 0
The V/f curve setting determines the profile of the V/f ratio that will be followed in the scalar operation
of the drive.
In other words, it defines the nature of variation of the output voltage to the output frequency.
Depends on Model
Depends on Model
