Selec VFD Series

20
User Manual
Fun.
Code
Description Settings and Range
Default
Value
Basic
Setting
Modifi-
cation
M-bus
Address
P5-06
Lower Limit OF AI2
0.0 – 100.0 % 0.5 %
Yes
40506
P5-07
Corresponding
Setting of AI2
Lower Limit
0.0 – 100.0 % 0.0 %
Yes
40507
P5-08
Upper Limit OF AI2
AI2 Lower Limit – 100.0 % 100.0 %
Yes
40508
P5-09
Corresponding
Setting of AI2
Upper Limit
0.0 – 100.0 % 100.0 %
Yes
40509
P5-10
AI2 Input
Filtering Time
0.0s- 10.0 s 0.1 s
Yes
40510
P5-11
AI2 Signal Loss
Threshold
0.0 to AI2 Lower Limit
0.5 %
Yes
40511
P5-12
PNP/NPN Selection
0: NPN; 1: PNP
1
Yes
40512
P5-13
Multifunction
Input X1
0: Disable
1: Forward Rotation
2: Reverse Rotation
3: Three-Wire Control
4: Multiphase Reference
Velocity 1
5: Multiphase Reference
Velocity 2
6: Multiphase Reference
Velocity 3
7: Forward JOG
8: Reverse JOG
9: Increasing Frequency
10: Decreasing Frequency
11: Acc- Dec Time option 1
12: Acc- Dec Time Option 2
13: Stop of Acc- Dec
14: External Fault Input
15: Fault Reset
16: Regular Stopping
17: External Count Value
Input
18: Count Clear
19: Program Run
20: Pause of Program Run
21: DC Brake
22: E-Stop
23: Hand Function
1
Yes
40513
P5-14
Multifunction
Input X2
2
Yes
40514
P5-15
Multifunction
Input X3
7
Yes
40515
P5-16
Multifunction
Input X4
14
Yes
40516
