Sensus iCon APX - Page 15

System Architecture Meter Overview
2-4 Meter Overview TM-iX0A-0805
Figure 2-4 through Figure 2-6 provide views of the available APX meter Forms.
Figure 2-4 shows a transformer rated Form 9S (8S) Meter Base.
Figure 2-4: Form 9S (8S) Meter Base
Figure 2-4 shows a Form 16S (14S, 15S, 17S) Meter Base.
Figure 2-5: Form 16S (14S, 15S, 17S) Meter Base
