Page #109 background image
5
Electrical installation
Assignment of the optional plug connectors
Operating Instructions – MOVIMOT
®
flexible
109
Connection cables
The following table provides an overview of the cables available for this connection:
Connection cable Conformity/
part num-
ber
Length/in-
stallation
type
Operating
voltage
Connection to interface adapter USM21A: CE:
28111680
3.0m DC60V
M12, 5‑pin,
A‑coded, male
RJ10
Connection to CBG.. keypad: CE:
28117840
3.0m DC60V
M12, 5‑pin,
A‑coded, male
D‑sub, 9‑pin,
male, angled
29129451/EN – 12/2019
