Electrical installation
PC connection
Operating Instructions – MOVIMOT
®
flexible
129
5.13.2 Connection via CBG21A or CBG11A keypad
Use the CBG21A or CBG11A keypad to connect the PC and the engineering interface
of the device.
The data is transferred according to the USB 2.0 standard. It is also possible to work
with a USB 3.0 interface.
You need the following components for the connection:
Component Part number
CBG21A keypad 28238133
CBG11A keypad 28233646
CBG.. connection cable D‑sub/M12
For connecting the X4141 engineering interface to the 24V supply
voltage
• With D‑sub plug connector 9-pin, male
• With M12 plug connector, 5-pin, male, A-coded
• Length: 3m
28117840
CBG.. connection cable D‑sub/RJ10
For connecting the X31 engineering interface to the 24V supply
voltage
• With D‑sub plug connector 9-pin, male
• With RJ10 plug connector
• Length: 3m
28117832
USB connection cable USBA/USB2.0 MiniB
For connecting the CBG.. keypad to the USB interface of the PC
• With USBA plug connector
• With USB2.0MiniB plug connector
• Length: 3m
25643517
29129451/EN – 12/2019
