SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series User Manual

11
Technical data and dimension sheets
Braking resistors
Operating Instructions – MOVIMOT
®
flexible
317
11.5.4 Technical data of BW100-005/K-1.5 and BW150-003/K-1.5
Power diagrams
The following figure shows the rating diagrams of the braking resistors BW100-005/
K-1.5, BW150-003/K-1.5:
0.2
2.0
0.4
0.6
0.8
0.1
1.0
[1]
[2]
6 7 8 9 1003 4 5 10 20 30 40 50 60
70
80
BW100-005
BW150-003
25298658059
[1] Power in KW
[2] Cyclic duration factor cdf in %
Dimension drawing of BW150‑003/K-1.5
The following figure shows the dimensions of the external braking resistor
BW150-003/K-1.5:
110
146
10
6
60
15
15.5
80
98
4,6
Ø8
1500
25298773259
29129451/EN – 12/2019

SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series Specifications

General

Brand	SEW-Eurodrive
Model	MOVIMOT flexible MMF1 C/DBC Series
Category	DC Drives
Language	English
