1-76
BEFORE USING THE MACHINE►LOADING PAPER
Changing the paper size for the large capacity tray (MX-LCX3 N)
1
Loosen the paper guide screw.
2
Slide the plate of the paper guide.
Slide the plate until the red line appears at the center of the
size window of the plate.
3
Adjust the paper guide to the paper
size that will be used.
Slide the paper guide forward or backward until the size
mark of the paper to be used ( or ) appears in the size
window of the plate.
4
Secure the paper guide.
(1) Slide the plate of the paper guide.
Slide the plate until the paper size to be used appears
in the size window of the plate.
(2) Tighten the paper guide screw.
5
Repeat steps 1 through 4 to adjust the
far paper guide to the paper size to be
used.
Be sure to adjust the far paper guide to the same paper size
as the near paper guide.
Adjusting only one paper guide may result in skewed feeding or misfeeds.
To Next Page
