Control devices and controls
The fuel tank tap
Electric star button
Choke lever
The fuel tap is located on the bottom left-hand side
of the fuel tank.
It has 3 positions:
ON – Fully open, to allow fuel to ow through.
OFF – Access to fuel ow shut off.
RES – Access to the 0.5 litres of reserve fuel.
The switch is located on the right-hand side of the
handlebars.
To start the motorcycle using the electric starter:
- Press the button .
There is no need to turn the throttle twist grip during
starting. Release the button once the engine has
started.
The choke lever is located on the right-hand side of
the carburettor.
ON : increases the richness of the mixture.
OFF : keeps the richness of the mixture at a
suitable level.
Turning the choke on:
- Press the lever upwards and turn it inwards until
it holds in position.
Turning the choke off:
- Press the lever downwards and turn it outwards
until it releases.
WARNING
A
RES
OFF
ON
B
A
A
A
B
