51
ENGLISH
51
Changing the brake light
Changing the fuse
This operation should be performed with the ignition
off.
Removal:
- Remove the 3 screws and washers from the
rear mudguard.
- Disconnect the wiring terminal .
- Remove the brake light.
Type: the brake light is a LED unit and the complete
assembly needs to be renewed.
Retting:
- To ret, proceed in reverse order to removal.
This operation should be performed with the ignition
off.
The fuse is situated below the fuel tank, and
therefore the following have to be removed:
- The seat (Seat chapter).
Removal:
- Remove the rear mudguard by removing the
front screw .
- Remove the box-lter support together with
the air lter box.
ATTENTION
ATTENTION
A
A
B
A
A
B
B
