Adjusting the throttle cable
The throttle cable play is factory set, although the
user can also adjust it:
To access the throttle cable adjustment shaft, the
seat will rst have to be removed (Seat Sect.).
- Remove the fuel tank by pulling it backwards.
- Loosen the locking nut .
- Screw the threaded shaft in or out .
- Lock the position with the locknut .
After adjustment, start the engine and turn the
handlebar to both sides to make sure there are no
accelerations produced by the cable being too tight.
The throttle cable should NEVER be under tension
when closed.
The throttle twist grip should have a free play of 2
to 3 mm.
WARNING
WARNING
C
D
B
A
A
B
B
C
