Maintenance processes
Position of the front brake lever
In order to be able to pull on the lever properly
during the braking operation, the position of the
lever needs to be adapted to the physique of the
rider.
To alter the position:
- Loosen the 2 screws on the lever-reservoir
assembly .
- Sit on the seat.
- Place your feet on the footrests.
- Place your hand on the lever and position it as
desired.
- Secure the position by tightening the two
screws .
To change the distance between the lever and the
throttle twist-grip:
- Screw or unscrew the threaded screw .
Turn to the right for a SHORTER DISTANCE.
Turn to the left for a LONGER DISTANCE.
After changing the position, check and adjust the
play in the front brake.
ATTENTION
WARNING
The hand should be in a relaxed
position and able to apply pressure
on the lever.
B
A
B
A
A
A
