Set Value Function
0
Operation of the power button from the instrument is disabled according
to the control of the system controller only. (Initial value)
1
In addition to being controlled by the system controller, it is also possible
to turn off the power individually from the instrument.
When the instrument is connected to the system controller SCL-40/CBM-40, the power
control of the instrument follows the system controller, and the shutdown and startup
functions operate from the system controller throughout the system.
If you turn off the power to the instrument individually with the setting [1], the
connection to the system controller will also be lost. Therefore, the system
startup function does not turn on the instrument. you need to turn the power
on again by pressing and holding the power button on the instrument.
The system shutdown function is still enabled with setting [1]. However, if the
power is turned off by the shutdown function, turning on the power by pressing
the power button of the instrument is disabled, and the system must be started
up from the system controller.
n Setting the function of the EVENT1 output terminal《SELECT EVENT1》
Not used in CL model.
Do not change the factory default value.
Sets the control mode of the [EVENT1]
output (relay 1).
Input the value with the numeric keypad
and press [Enter].
Set Value Function
0 The EVENT1 output is controlled with the [EVENT1] set value.
1 The EVENT1 output is used as a start signal of a time program.
If the [SELECT EVENT1] function is used, the corresponding [EVENT1] parameter
is disabled.
CTO-40C CL
25
3.4 Auxiliary Functions Screen (FUNCTION)
3
