2-2
IRAffinity-1
Chapter 2 Specifications
The specifications of IRAffinity-1 are as follows.
The IRPrestige is not in conformance with IEC60601.
2.1.1 Hardware (Except PC)
Interferometer Michelson interferometer (incident angle is 30 degrees)
Dynamic alignment system
With auto drier, sealed interferometer
Optical system Single beam
Beam splitter Ge coated on KBr
Light source Air cooling type ceramic (guaranteed for 3 years)
Detector DLATGS detector with temperature control system
Wavenumber range 7,800 to 350 cm
−1
Resolution 0.5, 1, 2, 4, 8, 16 cm
−1
Wavenumber accuracy
±0.125 cm
−1
(NOTE1, 2)
S/N ratio 30,000 : 1 (Peak-Peak, Resolution 4 cm
−1
, around 2100 cm
−1
, integrated for
1 minute)
Mirror speed 4 step (2.0, 2.8, 5, 9 mm/sec.)
One-time integration at 4 cm
−1
resolution and 2.8 mm/sec. mirror speed take
about 2 to 3 sec.
Data sampling He-Ne laser used (guaranteed for 30 months)
Gain Automatic or manual (×1 to ×128)
Sample compartment Automatic recognition system of accessories
200 (W) × 230 (L) × 170 (H) mm
Center focus
Dimensions 514 (W) × 606 (L) × 273 (H) mm
Weight 35 kg
NOTE
1. Resolution and wavenumber accuracy of the FTIR are determined by the wavenumber interval of
spectral data. Since the maximum data interval of IRAffinity-1 is 0.25 cm
−1
, the peak position can be
read at an accuracy of ±0.125 cm
−1
. In case of the asymmetric peak, however, the accuracy for reading
the peak position should be ±0.25 cm
−1
.
2. The calculation of wavenumber accuracy based on the wavelength of the He-Ne laser is ±0.01 cm
−1
.
2.1 IRAffinity-1 Specifications
