4-10
IRAffinity-1
Chapter 4 Operations
4.6.3 The Way to Move Sample Position
This section describes the way to move sample position.
Current position
The current position is displayed at the "Position" part.
Relative movement
Move to the Previous or Next position.
Click the [Prev.] or [the Next] button at the [Control] part.
• When the current position is the last sample position of the ASC, the [Next] button moves to
the first position (initialized position).
• When the current position is the first sample position (initialized position) of the ASC, the
[Prev.] button moves to the last sample position.
Absolute movement
Move to the specified position.
Input the sample position number at the [Control] part, and then click the [Move to] button.
• If input number exceeds the "Maximum" of the ASC setting, an Error message is displayed.
Fig. 4.9 [Sampler] Dialog Box
Current Position
Position movement control
