5-18
IRAffinity-1
Chapter 5 Maintenance and Inspection
(*) The supplemental disk may not be included or the part number may be changed for upgraded versions.
Name Unit Part No.
1 Silica gel 1 200-53655
2 Polystyrene film (approx. 50 μm thickness) 1 202-30689-01
3 Standard Cassette (Slide-mount sample holder) 1 206-70001
4 Optional Cassette (Slide-mount sample holder) 1 206-17384
5 Screw for Slide-mount 1 037-02820-18
6 Sample compartment cover 1 206-71762-12
7 Sample compartment sub-cover 1 206-71764-10
8 Light Source Assy 1 206-70106-91
9 DLATGS Detector MTG-21 1 206-72234
10 Laser Assy 1 206-73369-91
11 Laser Power Supply Assy 1 206-72343-91
12 Piezo Assy 1 206-17317
13 Moving Mirror Assy 1 206-17331-05
14 Fixed Mirror Assy 1 206-70012-91
15 ASC cable 1 206-73433-91
16 AC cable (for 100 to 120 V) 1 071-60816-12
AC cable (220 to 240 V) 1 071-60825-51
17 Fuse 4 A 1 072-02004-22
18 Dry Unit Assy 1 206-73531-91
19 PCB Assy Power 1 206-73374-91
20 PCB ASSY CPU 1 206-73409-91
21 PCB ASSY LASER DETEC 1 206-73419-91
22 IRsolution 1 206-73800-91
23 Supplemental Disk
(*)
1
NOTE
• He-Ne laser assy is a consumable part. Replacement may be required every year. This however
depends on condition.
• Dry unit assy is a consumable part. Replacement may be required periodically year. This however
depends on condition.
5.9 Maintenance Parts and Consumable Parts
