4-8
IRAffinity-1
Chapter 4 Operations
Auto Sample Changer (ASC) such as DRS-8010ASC, ASC-8000T, Auto Sample Switcher must be connected
to IRAffinity-1 before turning ON.
4.6.1 Installation and Setting Up
1. Shut down your PC and FTIR.
2. Place your ASC on the FTIR sample compartment.
3. Connect the ASC cable of the accessory to the ASC port in the Sample compartment.
4. Turn on the FTIR.
5. Turn on the PC, and then activate the IRsolution software.
6. Select [Measurement]-[Initialize].
7. Select [Measurement]-[Auto Sampler]. The [Sampler] dialog box is displayed.
Fig. 4.7 [Sampler]
8. Select either "ASC-A".
9. Select your accessory on the "Accessory" section. Selecting following accessory sets up
"Maximum" and "Pulse No." automatically.
10. Put a check mark on "both", and then click the [Initialize] button to initialize the accessory.
NOTE
The Auto sample changer connector is an optional extra.
NOTE
Energy (power spectrum) check is performed during initialization of IRAffinity-1. When an
accessory interrupts IR beam, the check may be faulty.
ASC Accessory
ASC-8000T ASC-8000T
DRS-8010ASC DRS-8010
Auto Sample Switcher ASS-8000
4.6 Auto Sampler
