６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - ３６
10. As shown in Fig. 6-56, loosen the hexagon socket head cap screws that fix the wheel.
Fig. 6-56 Loosen the Fixing Bolts of the Wheel
Hexagon socket head
cap screws
