６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - １６
Fig. 6-27 Removing the Left Rotation Unit and Removed Parts
Fig. 6-28 Removing the Right Rotation Unit and Removed Parts
Left rotation unit
Remove these socke
t
head cap screws (in
4
positions).
Right rotation unit
Parts of left rotation unit
Remove this
U nut.
Before remo
v
in
g
this rotation stopper,
mark the attachmen
t
p
osition.
Parts o
f
right
rotatio
n
unit
Remove these socke
t
head cap screws (in
4
positions).
It is
double-faced.
