Shure Microflex Advance MXA910 User Manual

Web Conferencing Software With Dante™ Virtual Soundcard
reset
PoE
OUTPUT
௢
௟
௡
௣
௠
Ceiling array microphone
Network switch
Shure ANI4OUT
Ceiling speaker
① Array microphone to network switch
Connect the array microphone output with a network cable to any port on the switch that supplies Power over Ethernet (PoE).
② Computer to network switch
Connect a computer to the network switch to provide control of the array microphone and other networked components through the software control panel. The
computer also runs Dante™ Virtual Soundcard, Dante™ Controller, and the web conferencing software.
Shure IncorporatedMXA910 Ceiling Array Microphone
11/572017/10/18

Shure Microflex Advance MXA910 Specifications

General

Type	Ceiling Array Microphone
Bit Depth	24-bit
Sampling Rate	48 kHz
Color	White
Connectivity	Dante, Ethernet
Output Connector	RJ45
Signal to Noise Ratio	72 dB (A-weighted)
