⑤ Channel Name
Channel names are customizable and apply to any linked microphone. The name persists even if a different microphone is linked.
⑥ Microphone Link Slot
Selects the which microphone displays on the channel strip.
Note: One microphone is on-air per channel, though an alternate microphone can be prepared in the secondary link slot.
⑦ Identify Button
Commands the microphone to flash its LEDs to easily identity which device corresponds to the channel.
⑧ Microphone Status and Control
View or change the microphone state:
• Active: On and passing audio to the network.
• Mute: On but the audio is muted.
• External: On and passing audio to an external controller that controls the mute/active behavior.
• Standby: On but in a 'sleep' state with audio muted. Standby conserves battery charge and enables a change to the microphone's status from the control
software.
• Charging: Battery is charging.
• Inactive: Off or out-of-range. A microphone in this state cannot be remotely controlled by the software.
• Power Off: Turn off the microphone.
⑨ Battery Status
• In the charger: Displays the remaining time until the microphone battery is fully charged
• Out of the charger: Displays the remaining battery runtime of the microphone.
⑩ Audio Input Meter
Indicates the average input signal level.
DescriptionAudio Signal Level (dBFS)Color
Overload0 to -9Red
Normal peaks-9 to -18Yellow
Signal Present-18 to -60Green
⑪ RF Signal Strength
Indicates the signal strength of the microphone. When the bars are grey, the microphone is out of range.
⑫ Mic Gain
Adjusts microphone gain from -25 dB to +15 dB gain in 1 dB steps.
⑬ High-Pass Filter
Engages a 12 dB-per-octave filter below 150 Hz for attenuating undesired low frequencies, sometimes caused by table vibrations or air-conditioning rumble.
Automatically enabled in high channel density mode (HD).
⑭ Low-Pass Filter
Engages a 6 dB-per-octave filter above 12 kHz for attenuating undesired high frequencies, sometimes caused by sibilant vocals or paper rustling. Automatically
enabled in HD mode.
⑮ Microphone Type
Displays the microphone type.
⑯ Link/Unlink Buttons
For setting up a single audio channel. Links the microphone to the primary or secondary link slot (as selected at the top of the channel strip).
• Link: Links the microphone from the corresponding charging slot.
• Unlink: Unlinks the microphone from the audio channel.
⑰ Bodypack Mic Options
There are two input sources available on the MXW1 bodypack: the internal, omnidirectional microphone or the external, TQG input for lavalier or headset micro-
phones. Select the input source preference:
• Auto: The internal mic is used until the MXW1 detects a connection at the TQG input. The microphone automatically selects the external source whenever
available.
• Internal: Audio source is always from the internal microphone.
• External: Audio source is always from a connected microphone. (Internal mic is off.)
⑱ Return Channels
Monitor the signal level and mute/unmute the audio of the return channel. Disabled in high density mode (HD).
