8
Read trigger (switching input)
9
Alternative: GSD configuration (central via PROFINET controller)
ß
Male connector, M12, 4-pin, A-coded, split into 2 x female connectors, M12, 5-pin, A-
coded
3.2.4 Product features and functions
Table 6: Overview of product features and functions of the device
Product feature/function Characteristic
CLV61x Dual Port bar code scanner
■
Fixed focus
■
Red light line scanner or grid scanner
■
Reading range: Long range, optimized for intralogistics applications
■
Medium resolution
■
Additional scanning frequency range (400 Hz ... 1,000 Hz)
■
Option to adapt to code print quality
■
Evaluation range of scanning line can be limited
■
Trigger input for reading pulse, type-dependent, identifier see "Type code",
page 13
Safety and ease of use
■
Rugged, compact metal housing, CE marking
■
Laser Class 2, laser switches off if the output power is exceeded
■
Automatic self-test on system start
■
Diagnostic tools for device setup and (remote) device monitoring
■
Configurable output of reading diagnostic data in two reading results formats
■
Operating data polling, in case of error, issue of error code if required
■
Test string function (heartbeat) can be activated to signal that the device is
ready for operation
■
Password-protected configuration mode via SOPAS ET
■
Protection of centrally configured parameter values in the PROFINET con‐
troller (e.g., PLC) via GSD parameterization
■
Optional backup of locally configured parameter values on microSD memory
card in the device, type-dependent, identifier see "Type code", page 13
■
Future-proof through firmware update (FLASH PROM) via data interface
■
Future-proof SOPAS ET configuration software
■
Low power consumption
■
Additional supply voltage range
■
Wide range of ambient operating temperatures
■
Device variants suitable for cold stores, type-dependent, identifier see "Type
code", page 13)
Easy configuration/operation
■
Configuration centrally using PROFINET controller (e.g., PLC) via GSD parame‐
terization or locally via SOPAS ET configuration software (incl. online help
function)
■
Status display by five LEDs
■
Configuration via profile programming with bar codes, generated and printed
with the help of SOPAS ET
Reading Operation Mode
■
Start/stop operation (one bar-code bearing object per reading pulse)
Read pulse generation
■
Pulse source for start: Fieldbus input, data interface (command), auto pulse,
free
■
Pulse source for stop: Read pulse source, data interface (command), timer,
condition
Bar code evaluation
■
All current 1D code types
■
Max. number of bar codes: 50 per read pulse
■
Separation of identical codes of the same code type by read angle
Data Processing
■
Influencing the output of the reading data by event-dependent evaluation con‐
ditions
■
Influencing the output string by filtering and output sorting
3 PRODUCT DESCRIPTION
