SICK CLV61 Series User Manual

3
CMC600 parameter cloning module (optional)
4
Auxiliary interface “AUX”
5
Male connector, D-Sub, 9-pin
6
Name of the digital output
7
e.g. PLC (programmable logic controller)
8
SCANNER = Device
9
Female connector, D-Sub-HD, 15-pin
ß
Device to be connected
à
The optional CMC600 parameter cloning module is required in the connection module in order to use the additional
external digital inputs and outputs of the device (highlighted in gray).
14.7.3 Connecting supply voltage for the device in CDM420-0006
Device = CLV61x-xx0xxx (serial variant)
Device 3CDM420-0006
V
S
1
5
5
Shield
1 +24 V
2 GND
+24 V*
GND
S1
F
Shield
GND
.
.
.
.
.
.
ON
OFF
S1 : POWER
+24 V*
POWER
V
S
GND
V
S
- +24 V -
F
S 1
- +24 V*
4
V
s
1
110
15
6
11
5
Cable 2
Figure 64: Connecting supply voltage for the device in CDM420-0006 connection module
1
Supply voltage V
S
2
Connecting cable permanently connected with the device (male connector, D-Sub-HD, 15-pin)
3
Device
4
Connection module: female connector, D-Sub-HD, 15-pin
Function of switch S1
Table 45: Switch S1: Power
Switch setting Function
ON Supply voltage +24 V connected to CDM420-0006 and device via fuse
as +24 V* supply voltage
Supply voltage +24 V* can be additionally tapped at terminals 29 and
39
OFF CDM420-0006 and device disconnected from supply voltage
Recommended setting for all connection work
14.7.4 Wiring serial host interface RS-232 of the device in the CDM420-0006
14 ANNEX
102
O P E R A T I N G I N S T R U C T I O N S | CLV61x 8017840/19OF/2021-10-28 | SICK
Subject to change without notice
