12 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/CLV61x
Please note: This documentation may contain further technical data.
12.1
Features
Table 16: Technical data features
CLV610 CLV612 CLV615
Work area Mid range Short Range Long Range
Scanning methods Line scan or raster scan
1)
, type-dependent
Sensor type Line scanner or raster scanner, type-dependent, identifier see "Type
code", page 15
Orientation of viewing
window
Front or side
2) 3)
, type-dependent, identifier
see "Type code", page 15
On the side
2) 3)
Aperture angle ≤ 50°
Optical focus Fixed focus
Code resolution 0.2 mm ... 1.0 mm 0.1 mm ... 0.2 mm 0.35 mm ... 0.5 mm
Reading ranges see "Reading field diagrams (working ranges)", page 64
Scanning frequency 400 Hz ... 1,000 Hz
Light source Laser diode, visible red light (λ = 655 nm)
Light spot Circular
MTTF (laser diode) 40,000 hours at 25 °C
MTBF 100,000 hours
Laser class Class 2 according to EN/IEC 60825-1:2014. Identical laser class for
issue EN/IEC 60825-1:2007.
Conforms to 21 CFR 1040.10 except for deviations per Laser Notice
No. 50 of June 24, 2007, and subsequent versions.
Laser power P = 1.5 mW maximum, P < 1.0 mW average
Laser pulse duration < 300 μs
1)
Front viewing window: 8 lines, grid height approx. 15 mm at reading distance 200 mm.
Side viewing window: 8 lines, grid height approx. 15 mm at reading distance 185 mm.
2)
Side viewing window: Light emission at 105° relative to the longitudinal axis of the device.
3)
see "Device view", page 17.
12.2 Performance
Table 17: Technical data for performance
CLV610 CLV612 CLV615
Readable code struc‐
tures
1D codes
Bar code types Code 39, Code 128, Code 93, Codabar, UPC / GTIN / EAN, 2/5 Inter‐
leaved, Pharmacode
Print ratio 2:1 ... 3:1
TECHNICAL DATA 12
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
61
Subject to change without notice
