3.1.2 Type code
The devices of the CLV61x product family are arranged according to the following type
code:
CLVxyz-abcdef
CLV x y z ‒ a b c d e f
1 2 3 4 5 6 7 8 9 10
Table 2: Type code
Position Description Characteristic
1 Code reader, V principle ‒
2 – 3 Product family 61: CLV61x
4 Working range 0: Mid range
2: Short range
5: Long Range
8: Long range
5 Performance C: CAN
D: Dual Port PROFINET
F: Fieldbus (Dual Port) over external fieldbus mod‐
ule CDF600-2
I: IO-Link
6 Reading method, orientation
of viewing window
1)
0: Line scanner, viewing window on front side
1: Raster scanner, viewing window on front side
2: Line scanner, viewing window on the side
3: Raster scanner, viewing window on the side
7 Electrical connections
(design)
0: Cable 0.9 m with male connector, D-Sub-HD,
15-pin
1 = Swivel connector with 1 male connector, M12,
5-pin, A-coded and 1 female connector, M12, 5-pin,
A-coded
4: 1 swivel connector with 2 female connectors,
M12, 4-pin, D-coded. 1 cable 0.9 m with male con‐
nector, M12, 4-pin, A-coded
5: 1 swivel connector with 2 female connectors,
M12, 4-pin, D-coded. 1 cable 0.9 m with male con‐
nector, M12, 5-pin, A-coded
8 Interfaces, storage media 0: Host (RS-232), AUX (RS-232), 2 digital inputs, 2
digital outputs
1: Host (Ethernet), AUX (Ethernet, USB
2)
)
2: Host (Ethernet), AUX (Ethernet, USB
2)
), 1 digital
input
3: Host (Ethernet), AUX (Ethernet), 1 external
parameter memory (microSD memory card)
3)
4: Host (Ethernet), AUX (Ethernet), 1 external
parameter memory (microSD memory card
3)
), 1
digital input
5: IO-Link, 1 digital input (hardware)
9 Window material of the view‐
ing window
0: Glass
1: Plastic
10 Ambient operating tempera‐
ture
Without marking: Standard (0 °C ... +40 °C)
F0: Extended (-35 °C ... +40 °C, with integrated
heating)
Enclosure rating: IP65
1)
Refers to the longitudinal axis of the device.
2)
The USB interface is only for temporary use by the user as a service interface.
3)
For service functions such as parameter cloning.
PRODUCT DESCRIPTION 3
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
15
Subject to change without notice
