5 Mounting
5.1 Overview of mounting procedure
•
Selecting and preparing the mounting location.
•
Mounting the device.
•
Connect device to combined data and supply cable.
•
Align the device towards object with bar code.
•
Adjust the device.
NOTICE
Danger due to damage to the device
For reasons of safety, if a device shows visible signs of damage do not put it into
operation. Immediately take a device that is in operation out of operation.
Damage includes, depending on the type of device, for example the following:
•
Viewing window pane: Cracked or broken
•
Housing: Cracked or broken
•
Violation of the cable outlet on the housing or the cable itself
•
Overtightening of the male connector unit, tearing or breakage of the housing
•
Moisture penetration in the device
5.2 Preparing for mounting
5.2.1 Mounting requirements
NOTE
Radio interference may occur when the device is used in residential areas!
■
Only use the device in industrial environments (EN 61000-6-4).
Space requirements
■
For typical space requirements for the device: See type-specific dimensional draw‐
ing and reading field diagram.
■
The device requires a direct, unimpeded line of sight to the codes being read.
■
Make sure path between the bar code and the viewing window of the device is
of sufficient size. The light reflected from the bar code must be able to reach
the viewing window without interference. This means that there must be a free
corridor along the entire light path. The height of the corridor must be at least
equal to the height of the viewing window.
Environmental influences
■
Comply with technical data, e.g. permissible ambient conditions for operating the
device (temperature range, EMC interference emission, ground potential), see
"Technical data", page 61.
■
To prevent the formation of condensation, avoid exposing the device to rapid
changes in temperature.
■
To avoid additional external heating of the device during operation or optical
device dazzle, protect the device from direct or indirect sunlight.
Enclosure rating
■
For further information, see "Conditions for specified enclosure rating", page 8
Mounting
5
MOUNTING
26
O P E R A T I N G I N S T R U C T I O N S | CLV61x 8017840/19OF/2021-10-28 | SICK
Subject to change without notice
