12.5 Ambient data
Table 20: Technical data for ambient data
CLV610 CLV612 CLV615
Electromagnetic com‐
patibility (EMC)
Radiated emission: EN 61000-6-4: 2007-01 + A1: 2011-02
Electromagnetic immunity: EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating
temperature
0 °C ... +40 °C
Storage temperature ‒20 °C ... +70 °C
Permissible relative
humidity
0% ... 90%, non-condensing
Ambient light immun‐
ity
2000 lx, on bar code
Bar code print con‐
trast (PCS)
≥ 60 %
12.6 Dimensional drawings
Dimensions see "Device view", page 17.
12.7 Reading field diagrams (working ranges)
12.7.1 Reading conditions for specification diagrams
Properties Value
Test code Code 39 / ITF
Resolution See reading field diagrams in each case
Scanning frequency See characteristic curve fields for scanning frequencies
Print ratio 2:1
Print contrast > 90%
Tilt ±30°
Ambient light < 2,000 lx
Good read rate > 75%
Light spot Circular
Window material of the
viewing window
Glass (CLV61x-xxx0)
NOTE
The reading distances are measured radially from the device.
12 TECHNICAL DATA
64
O P E R A T I N G I N S T R U C T I O N S | CLV61x 8017840/19OF/2021-10-28 | SICK
Subject to change without notice
