CLV610 CLV612 CLV615
Acoustic indicators 1 beeper, can be switched off, can be allocated function for event
status indication
Control elements Configuration software
Service function Backup of parameterization data (parameter cloning) outside the
device memory: Optional CMC600 parameter cloning module in CDB
or CDM connection module
Configuration SOPAS ET configuration software, commands
1)
Via the optional CMC600 parameter cloning module in the CDB620 or CDM420 connection module.
2)
Input voltage.
3)
Input current.
4)
Output current.
12.4 Mechanics/Electronics
Table 19: Technical data mechanics/electrics
CLV610 CLV612 CLV615
Connection type 1 standard cable (0.9 m +10 %) with male connector, D-Sub-HD, 15-pin
Supply voltage V
S
•
10 V DC ... 30 V DC, with connecting cable 0.6 m to max. 3 m
•
12 V DC ... 30 V DC, with connecting cable 3 m to max. 6 m
LPS or NEC Class 2
Reverse polarity protected
Power consumption
1)
Typical 2.8 W
Housing Aluminum die cast
Housing color Light blue (RAL 5012)
Window material of
the viewing window
Glass, identifier see "Type code", page 15
Threaded mounting
hole
2 x 2 blind tapped hole M5, 5 mm deep
Tightening torque for mounting screws: max. 2.5 Nm
Laserwarnschild In combination with the type label, glued on
Safety EN 62368-1: 2014-08
Enclosure rating IP 65, in accordance with EN 60529:1991-10 + A1:2002-02
Protection class
(Class 3)
For operation in SELV systems (EN 60950-1) or ES1 systems
(EN 62368-1)
Weight
2)
Device with front viewing window: 265 g with cable 0.9 m
Device with side viewing window: 295 g with cable 0.9 m
Dimensions (L x W x
H)
3)
Device with front viewing window: 61 mm x 66 mm x 38 mm
Device with side viewing window: 80 mm x 66 mm x 38 mm
Conformities CE, UL
4)
For further conformities and certificates, see the product page on the
Internet at: www.sick.com/CLV61x
1)
For digital outputs without load.
2)
Without connecting cable and male connector, pane of the viewing window made of glass.
3)
see "Device view", page 17.
4)
Only UL-certified if the type label contains the UL logo and the UL conditions are complied with during
device operation. For further information, see "UL conformity", page 74.
TECHNICAL DATA 12
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
63
Subject to change without notice
