SICK CLV61 Series User Manual

Device = CLV61x-xx0xxx (serial variant)
Device 1 CDM420-0006 Host
5
.
.
.
TxD
RxD
RxD
TxD
GND
GND
GND
9
7
34
T‒/TxD
35
R‒/RxD
36
GND
6
Shield
RS-232 RS-232
S2
OFFON
110
15
6
11
5
3
Cable 2
ON
OFF
S2 : RS 485
ON
OFF
S3: Term 422
Figure 65: Wiring data interface RS-232 of the device in connection module CDM420-0006.
1
Device
2
Connecting cable permanently connected with the device (male connector, D-Sub-HD, 15-pin)
3
Connection module: female connector, D-Sub-HD, 15-pin
NOTE
Activate the RS-232 data interface in the device with a configuration tool, e.g., the
configuration software SOPAS ET.
14.7.5 Wiring the CAN interface of the device in the CDM420-0006
Device = CLV61x-xx0xx (serial variant)
ANNEX 14
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
103
Subject to change without notice
